Migration to Open Source Databases

Migration to Open Source Databases Jutta Horstmann www.osdbmigration.org

whoami ● Unix/Linux sysadmin ● DBA, developer (Informix) ● DB developer (Oracle) ● Web stuff (MySQL, PostgreSQL) ● Claim to Fame: OpenUsability.org ● Comp Sci Diploma Thesis: Migration to Open Source Databases Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 2

Agenda ● What’s this? ➔ About ● Why migrate? ➔ Pros and Cons ● Where to migrate? ➔ Open Source Databases ● How to migrate? ➔ Workflow: Activities ● What to migrate? ➔ Workflow: Assets Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 3

Migration? “The process of changing from the use of one platform, environment, IT system, etc., to another, esp. in such a way as to avoid interruptions in service.” (Oxford English Dictionary) Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 4

Migration: Objectives The target system: The migration workflow: ● same functionality ● Minimize risk ● extendable ● Stay on budget ● incorporate all data ● Deliver in due time ● modern hardware, ● Minimize downtime software, architecture Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 5

OSDB Migration:Pros and Cons Yes No ● Cost? Time? Effort? ● Features? ● Lack of roadmap ● TCO ● Licensing ● Open Source ● ISV Support – Code Maintenance – Community ● ● ● Accountability Features Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org ● Standards ● Security ● Independence 6

Where to migrate? Firebird MaxDB PostgreSQL Ingres MySQL Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 7

Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 8

Enterprise-Level? Requirements: ● Advanced data integrity mechanisms ● Advanced database objects ● Advanced SQL features ● Advanced features, tools, support for Performance and scalability – (High) Availability – Security – Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 9

OSDB Features Firebird 1.5 Ingres r3 MaxDB 7.5 MySQL 4.1 Advanced Indexing MyISAM GIS support MyISAM MVCC InnoDB Two phase commit UD Functions v.5.0 v.7.6 PostgreSQL 8.0 v.8.1 v.5.0 UD data types Updatable Views Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org v.5.0 10

Performance / Scalability Firebird 1.5 Ingres r3 MaxDB 7.5 MySQL 4.1 PostgreSQL 8.0 Tablespaces Table Partitioning v.8.1 Parallelization Built-In Clustering Built-In Load Balancing Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 11

How to migrate? Database Migration Workflow ● Activity-Centered? ● Asset-Centered? ● Proposal: Mixed-Model Workflow ● Walk-Through Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 12

Activity-Centered Workflow Source System Analysis Source vs. Target System Design Target System Target System Implementation Test DBMS DBMS DBMS DBMS Data Data Data Data Schema Schema Schema Schema SQL SQL SQL SQL Infrastructure Infrastructure Infrastructure Infrastructure Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 13

Asset-Centered Workflow DBMS Source System Source vs. Target System Analysis Analysis Design Desig n Schema Analysis Analysis Design Desig n Data Analysis Analysis Design Desig n SQL Analysis Analysis Design Desig n Infrastructure Analysis Analysis Design Desig n Target System Implementation Implementation Implementation Implementation Implementation Target System Test Test Test Test Test Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 14

Mixed-Model Workflow 1. Analyze the whole source system (all assets). 2. Migrate the DBMS software (design, implement, test). 3. Migrate the schema(s) (design, implement). 4. Migrate test data (design, implement, test). 5. Test the migrated schema(s) with the test data. 6. Migrate the client SQL (design, implement, test). 7. Migrate the database system’s infrastructure (d, i, t). 8. Cut-over: Full data migration. 9. Final testing and evaluation. Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 15

Analyze the whole system Analysis DBMS ● How is the software configured? Schema ● Complexity, quality of database design? Data ● How much data? Which condition? SQL ● SQL isolated? Standard compliant? Infrastructure ● Tools, Policies, Tuning …? Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 16

Where to look? Who to ask? Documentation Application History ? Data Flows Processes Data Dictionary Data Developers, Admins, Users Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 17

Migrate the DBMS software DBMS Design Implementation Test

1. Choose Open Source DBMS 2. Devise mappings for configurations 3. Install & configure new software 4. Validate the working of the DBMS by using test databases and tools Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 18

Migrate the schema(s) 1. Provide abstraction (logical, conceptual?) Schema Design Implementation Test 2. Devise mappings to target system 3. Implement by loading converted schema into target system 4.Validate the schema’s correctness based on loading and querying test data. Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 19

Migrate Test Data 1. Correction and “cleansing” of “dirty data” Data Design Implement Test Data Test 2. Devise conversions and mappings 3. Transfer some test data: a) Extraction b)Transformation c) Load 4. Test: Errors at load? Query data! Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 20

Migrate Client SQL Database connectivity SQL ● Change ODBC/JDBC driver ● Switch client ● Client source available: Migrate! Design Implementation Test

1. Provide abstraction (Standard SQL) OR 2. Convert directly to target SQL syntax 3. Test statements against schema and test data Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 21

Migrate Infrastructure ● Infrastructure Tools: Administration, Development, Design ● Change ODBC/JDBC driver ● Switch client Design Implementation Test ● Administrative Tasks – Gather policies and jobs – Implement them in the target system way Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 22

Full Data Migration (Cut-Over) 1. Strategy: a) Cold Turkey? Data Design Implementation Test b) Chicken Little? c) Butterfly? 2. Data Transfer: Extraction, Transformation, Load 3. Test: Errors at load? Query data! Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 23

“Cold Turkey” ● Take source system offline ● Extract data ● Transform data ● Load data into target system ● Take target system online Problems: ● How long offline? How much data? ● Fallback? Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 24

“Chicken Little” ● Source and target system operate in parallel ● “Gateway” coordinates and maps queries ● Incremental data migration Problem: ● Complex implementation ● Update consistency? Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org Gateway 25

“Butterfly” ● Only source system online ● Data gets frozen read-only ● Store manipulation results in “Temp Store 0” ● Transfer frozen data ● Freeze TS0, store manipulation results in TS1 ● Transfer frozen data … and so on ● ● “Data Access Allocator coordinates and maps queries Problem: Complex implementation! Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 26

“Butterfly” Data Access Allocator Temp Store 1 Read-only TS 2 TS n TS n+1 Data Transformer Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 27

Summary: Problems ● Different SQL implementations ● User-defined data types/functions ● Stored Procedures ● Proprietary interfaces ● Flawed schema design ● Differences in Data Types ● “Dirty Data” ● Reserved Words Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 28

Help! - Migration Tools ● Automatization ● Integrity violation detection ● Re-Use ● Knowledge on source and target system ● Documentation ● Code Generation ● Script Scheduling ● Validation ● Speed! Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 29

Migration Tools, Examples ● Closed Source: – SQLWays (Ispirer). Only Windows. ● – ProgressionDB (Versora). Linux, Windows. ● ● Source: any, Target: MySQL, PostgreSQL MSSQL -> MySQL, PostgreSQL, Ingres Open Source: – Ingres Mio. $ Challenge (CA): shift2ingres – MySQL Migration Toolkit (MySQL AB) Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 30

Summary Migration to Open Source Databases ? ● Several Open Source options ● Migration is an ambitious project ● ● Workflow and results depending on state of source system Automatize the process, where possible! Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 31

Questions? Jutta Horstmann, OpenDB Con, Nov 8 2005. http://www.osdbmigration.org 32
